Under Cabinet TV Ceiling or Wall Mount Fits Monitors 17”-37”, Adjustable - Black

Under Cabinet TV Mount
  • Mounts 17”-37” Screens
  • VESA Compliant with 75x75, 100x100, 200x100, 200x200
  • 44 lb. Max. Weight Capacity
  • Height Adjustable
  • Ceiling or Wall Mounting
$34.92 / Each (USD)
Add To Cart Save to Wish List

Description

Under Cabinet TV Mount with Folding Design

An under cabinet TV mount is a great flat panel bracket for the home or office. Designed for a 17”-37” screen, this plasma display is a compact fixture for small LED monitors. The wall or ceiling TV mount folds at the base so it can be positioned as a hanging or fixed display as the spine adjusts to the different gradients. An LED screen with a 75x75, 100x100, 200x100, or 200x200 VESA standard sizes is compatible with this system. The height of the TV mount can be adjusted between 8-1/2” to 14” from the bracket backing, or the surface in which it is installed. The small flat panel fixture can hold up to 44 lbs. in weight.

Specifications

SKU LMCBN222A
Overall Width x Depth 8.8" x 3.3"
Weight 3.0lbs
Material Steel, Aluminum
Color Black, Silver
Placement Style Wall Mounted, Hanging
Orientation Portrait, Landscape
Features Lockable, Adjustable Height
Monitor Size Range, (inches) 17, 37
Distance Range From Ceiling, (inches) 8.5, 14.0
Mounting Bracket Width x Height x Depth 8.8" x 8.5" x 1.3"
VESA Size 75x75, 100x100, 200x100, 200x200
Max Monitor Weight 44.0lbs

Ordering Information

In Stock
Order by 2PM Eastern Time US for same day shipping.

Resources: Manuals, Videos, & Templates

Download LMCBN222A Assembly Instructions

Filename: lmcbn222a_instructions.pdf (291.01 KB)

Reviews

Browse reviews from customers who have already purchased this product.

Overall 3 out of 5 | 2 reviews


5 / 5
Great small Mount
on Verified Purchase
This worked perfect for the job i was doing i used 16 mounts and they all worked great.
Comments (1)
Thanks for the feedback, Chris! We hope to hear from you again soon.

Posted 5 months ago by Displays2go



1 / 5
Hole Alignment
on Verified Purchase
I purchased a LG TV 22" widescreen for the kitchen which was supposed to use the 100x100 pattern. Yeah not even close, and the spacers were a pain in the rear to keep positioned correctly. They should have had an adhesive back to stay in the correct position while you put the mount on. I had to make additional holes to get the mount onto the TV, since the hole pattern on the mount was off.
Comments (1)
Hi Michael, We are sorry to hear about the TV mount. A customer care specialist will be in touch.

Posted one year ago by Displays2go



Questions & Answers
